C-Special wall mounted LED display for stadium stands (P8)

P8,P10 C-Fit-Sport LED display adopt virtual replacement technology. Virtual ads could be transmitted to different countries instead of the real ads in stadium. Advantages: 1. Intelligent perimeter LED display. 2. Virtual replacement technology, powered by IR LED. 3. Fast Installation and maintenance cabinet design. 4. Soft protection kit design to protect players from harm. 5. Negative pressure heat-dissipation system, further guarantees the reliability. 6. Available for remote monitoring by App.

◙ The cabinet comes with a 90° rotating bracket and left and right fast locks for efficient assembly of the stadium LED display. ◙ The screen comes with soft mask and pillow protection, so athletes and the LED display are perfectly protected. ◙ Aluminum power box, thin and light, good heat dissipation, slowing down the aging of the power and module. ◙ Front and rear maintenance of the module, easy operation. ◙ Waterproof and dustproof, protection grade ≥ IP65. ◙ Energy-saving, about 1/3 energy saving than traditional LED display, greatly reducing the operating cost. ◙ Professional software, and supports video source input such as DP, HDMD, VGA, SDL, DVD, etc.

1. Flatness: ADC12 high strength die-cast aluminum cabinet, which can be assembled and disassembled frequently without deformation, good flatness. 2. Practical: Simple and practical design, firm handle, convenient fast lock, simple and practical. 3. Magnetic design: The magnetic module can be maintained from front and rear; the magnet between the cabinets are accurately positioned and installed, and very cost-effective for rental installation. 4. High protection: Corner protection+ anti-collision boss; Fully automatic protection of the surrounding Leds to avoid damage during transportation and installation; 5. Dual backup: Dual electric and signal backup can be selected to effectively solve the following problems: black screen, display error and unstable picture. 6. Over 5000m² global sales volume. Ready stock and fast delivery. 7. Multi applications: Support multiple installation methods such as floor-based mounting and hanging installation, and focus on providing customers in the fields of energy, justice, military, transportation, public security, finance, IT, etc. with overall solutions for visualization, intelligence, informatization, and digital LED display systems.

characteristic： 1.Strong visual impact: 360 degree viewing angle，pay videos in multiple directions to attract audiences and make the advertisement more visually impactful; 2.Simple play: Support one-click upload and playback via mobile APP, and realize remote seamless switching of advertising contents, simple and convenient; 3.Assembly-free：No assembly is required, simple installation, and ready to use; 4.Colorful: The cube LED display has a wide color gamut, supports thousands of colors, and perfectly reproduces the advertising; 5.Wide use: It is suitable for museums, science and technology exhibition halls, gymnasiums, waiting halls, star hotels, shopping malls, bars and other places.

C-Easy P5,P6.67,P8,P10,P16 is a front and rear serviceable, energy-saving, outdoor waterproof replaceable LED modules. Advantages: 1. Energy-saving≥30%. 2. Brightness≤8500Nits 3. High accuracy and high flatness. 4. Replaceable modules, fast and easy replace. 5. Front and rear service. 6. IP65 protection grade 7. 320*320mm module size, you can assemble it into different size screens.

Product Features: 1 High precision: the cabinets adopt high-pressure die-casting aluminum, and the tolerance is less than 0.1mm; this ensures accurate assembly of cabinets, and the surface of a whole screen will have good flatness; 2 Ultra-thin and ultra-light: the cabinet is 15kg/㎡ lighter in weight and 20% thinner than an iron cabinet; this will help you greatly reduce the cost of transportation, and the cost of construction of a steel frame structure; 3 Multiple purposes: the C-Fit billboard screen can be used as a cost-effective fixed display solution, rental display solution that supports hanging installation, and display solution for stadium perimeter fences; 4 Front-service design: the LED modules support front service; therefore, when it comes to wall-mounted installation, you can easily assemble and disassemble the modules; 5 Easy upgrade and replacement: the cabinets can adapt to our P4~P20 modules; therefore, you do not have to spend extra cost in replacing cabinets if you consider upgrading the billboard screen; 6 High brightness: the brightness level reaches more than 5500 CD/㎡; even though under strong light, the billboard screen still can present clear images; 7 High protection grade: the protection grade of the C-Fit-Easy series reaches IP65; and this type of billboard screen is very suitable for large-format outdoor advertisements, such as outdoor LED walls, and LED screens with a ground stack system;

1 The cabinets are made of die-cast aluminum and adopt ultra-light and ultra-thin design; the thickness of a cabinet (size:500*500mm) is only 87mm, and the cabinet weight is lower than 6.8kg; 2 The curved cabinets can be spliced with planar cabinets from the left and right sides; by the way, the C-Arc series can be spliced together with our C-Shine series (P2.604); so you can make cabinets with more shapes; 3 As a type of concave-convex curved LED screen, the curved angles (the angles of inner and outer arc) that the C-Arc series allows range from -30° to 30°； 4 The modules adopt soft PCB boards with special layout designs; this ensures that the arc surface of the screen is always smooth; 5 The cabinets adopt a no-fan design; the generated noise is always under 40DB when the screen is working; this will not impact the live visual and acoustic effects; 6 The C-Arc series presents HD visual effects – by the technology of white balance and point-by-point color calibration, the high uniformity and consistency of the images are guaranteed; 7 3 cabinets can be put together into a screen with a 90°arc; in other words, 12 cabinets can form into a circular-shaped screen; 8 As curved LED screens, the C-Arc series is widely used as stage screens for rental services, and mainly applied in trade shows and indoor stage shows; in addition, it can also be applied as indoor fixed screens;

1. Modular design with integrated power supply and receiving card, directly replace the traditional cabinet, saving the cost of the cabinet, only with a simple bracket for the installation; 2. Ultra-thin design, can be installed on the wall and maintained from the front and rear, convenient maintenance; 3. Unique mask design, deep black color and high contrast; 4. The module size is 640mm*320mm, larger size, better flatness; 5. The module uses 346 LEDs, with the characteristics of good heat dissipation and good weather resistance; 6. Constant current drive, 1/4 scan; 7. High brightness, up to 8500cd/㎡, and has the advantages of good light distribution curve and good angle consistency; 8. The protection grade for the module is IP65.
